Description
- High frequency design
- ow frequency stability
- Max efficiency up to 90%
- Over 2 times high surge power for motor rated application
- Soft-start to reduce inrush current
- Super loading ability
- Full protection:
Input protection: Reverse polarity / Over voltage / Low battery alarm and shutdown Output protection: Short circuit / Overload / Over temperature
- Ideal for powering inductive loads such as motor, and other sensitive loads, medical equipment and solar systems.
- 1 year warranty
- CE,Rohs & IEC approved
- rated application
- Soft-start to reduce inrush current
| Model No. | NW800 |
| Rated Power | 800W |
| 1000VA | |
| Surge Power | >1600W |
| Input Voltage | 12V/24V/48V DC |
| Output Voltage | 100 / 110 / 120V ± 5% or 220 / 230 / 240V ± 3% |
| Frequency | 50 / 60Hz +/- 0.3Hz |
| Output Waveform | Pure Sine Wave (THD < 3%) |
| Efficiency | 88% for 12V; 92% for 24V;93% for 48V |
| No Load Current Draw(A) | 0.6(12V), 0.3(24V), 0.2(48V) |
| Input Voltage Regulation | 11-15VDC / 22-30VDC / 44-60VDC |
| LED Indicator | Red LED indicates failure, Green LED indicates normal |
| Digital Display | Optinal |
| Protection | Overload, Short Circuit, Reverse Polarity (Fuse), Over Temperature, Low battery, High battery |
| Operating Temperature Range | 0 – 40℃ |
| Storage Temperature Range | -30℃ to 70℃ |
| Cooling | Temperature control the cooling fan |
| Dimensions(mm) | 280x153x70 |
| Weight( kgs) | 2.6 |
