Description
• High frequency design
• Max efficiency up to 90%
• 2 times high surge power
• Soft-start to reduce inrush current
• Super loading ability
• Full protection:
Input protection: Reverse polarity / Over voltage / Low battery alarm and shutdown
Output protection: Short circuit / Overload / Over temperature
• Ideal for powering the mine systems.
•1 year warranty
•CE,Rohs & IEC approved
| Model No. | NM1000UPS |
| Rated Power | 1000VA |
| 600W | |
| Surge Power | 2000VA/1200W |
| Input Voltage | 12/24/48V DC or 127VAC |
| Output Voltage | 127V±5% |
| Frequency | 50Hz +/- 0.3Hz |
| Output Waveform | Pure Sine Wave (THD < 3%) |
| Efficiency | 93% |
| UPS transfer time | 8ms |
| No Load Current Draw(A) | 0.4 |
| Input Voltage Regulation | 10-15/20-30/40-60 VDC or 90-165VAC |
| LED Indicator | Red LED indicates failure, Green LED indicates normal,Yellow LED |
| Digital Display | Alternate shows the DC input voltage and AC loading % of maximum load |
| Protection | Overload, Short Circuit, Reverse Polarity (Fuse), Over Temperature, Low battery, High battery |
| Operating Temperature Range | 0 – 40℃ |
| Storage Temperature Range | -30℃ to 70℃ |
| Cooling | Temperature control the cooling fan |
| Dimensions(mm) | 280x160x70 |
| Net Weight(kgs) | 2.3 |
| Qty | 4pcs/ctn |
| Inner Box(mm) | 360*270*130mm |
| Carton Size(mm) | 560*380*280mm |
